In the valve industry, the PTFE Valve Seat is an important component. Using PTFE, a synthetic fluoropolymer, provides a higher class of valve. PTFE has excellent properties like chemical inertness, low coefficient of friction, and excellent thermal resistance. Hence, the PTFE Ball Valve Seat is ideal for creating a tight seal between the valve body and the closure element (such as a ball, disc, or plug). The main function of using the PTFE Valve Seats for Ball Valves is to provide tight, leakproof, reliable, and efficient flow control. They are ideal for various industries.
Why Choose Us for PTFE Valve Seat
In the search for the best PTFE Valve Seat, Goa Polymer is the best. We are the leading PTFE Valve Seat manufacturer in India and supplier in India. Our PTFE (Polytetrafluoroethylene) valve seats are designed to provide higher performance, durability, and precision to a wide range of applications. We can meet your requirement for a high-quality Ball Valve Seat. Our Valve Seat is ideal for use in various industries such as chemical processing, pharmaceuticals, food and beverage, and more. Whether you require standard or custom valve seats, Goa Polymer will be the solution. Enhance your valve systems with our efficient and long-lasting Valve Seat.
Key Features of Our PTFE Valve Seat
PTFE Ball Valve Seat is ideal for use in a wide range of applications in different types of industries. Here are the key features of the PTFE Ball Valve Seat:
- Excellent Chemical Resistance: Valve Seat has excellent chemical resistance. Hence, it is ideal for use with a wide range of chemicals like acids, bases, and solvents. It does not react with chemicals and stays intact in an aggressive chemical environment. These Valve Seats do not degrade or corrode with chemicals.
- Low Friction: PTFE (Polytetrafluoroethylene) Valve Seat has low friction and non-stick properties. PTFE material provides smooth and wear-resistant properties to the valve, reducing the risk of the valve sticking and increasing its lifespan.
- High Temperature and Pressure Resistance: The Valve Seat has high temperature and pressure resistance, making it suitable for applications in extreme conditions. It is thermal environment-friendly, enhancing the performance of the Valve Seat.
- Dimensional Stability: The PTFE Ball Valve Seat has excellent dimensional stability. It does not change shape or size even under high load and pressure, making it suitable for high-load and high-pressure applications.
- Versatility: The PTFE Ball Valve Seat is versatile. PTFE can survive in all conditions, and the Valve Seat can be used with a wide range of fluids, including gases, liquids, and corrosive substances. Hence, it is used in various industries from chemical processing to food and beverages.
Mechanical Properties
| Property | Value | Standard (Norm) | Description |
|---|---|---|---|
| Tensile Strength | 20-35 MPa | ASTM D638 | Ability to withstand pulling forces without breaking. |
| Elongation at Break | 150-200% | ASTM D638 | Flexibility under tension before breaking. |
| Compressive Strength | 10-15 MPa | ASTM D695 | Resistance to compressive forces without deformation. |
| Hardness (Shore D) | 60-65 | ASTM D2240 | Surface hardness indicates resistance to indentation. |
| Density | 2.2-2.3 g/cm³ | ASTM D792 | Weight per unit volume. |
| Flexural Strength | 15-25 MPa | ASTM D790 | Ability to resist bending without breaking. |
Thermal Properties
| Property | Value | Standard (Norm) | Description |
|---|---|---|---|
| Service Temperature Range | -200°C to 260°C | – | Temperature range where the material can function effectively. |
| Short-Term Maximum Temp | 300°C | – | Maximum temperature the material can withstand for short durations. |
| Thermal Conductivity | 0.25-0.69 W/mK | ASTM C177 | Ability of the material or metal to conduct heat. |
Electrical Properties
| Property | Value | Standard (Norm) | Description |
|---|---|---|---|
| Dielectric Strength | 18-20 kV/mm | ASTM D149 | Ability to insulate against electric voltage. |
| Volume Resistivity | 10^17 Ohm·cm | ASTM D257 | Measure of electrical resistance across its volume. |
Other Properties
| Property | Value | Standard (Norm) | Description |
|---|---|---|---|
| Coefficient of Friction | Low (slightly higher than virgin PTFE) | ASTM D1894 | Measure of the material’s smoothness and movement. |
| Water Absorption | <0.01% | ASTM D570 | Low water absorption, making it ideal for moisture-rich environments. |
| Chemical Resistance | Resistant to most chemicals, except alkalis | – | Ability to withstand chemical corrosion. |
All PTFE Valve Seat Materials
Goa Polymer provides several material selections for the PTFE (Polytetrafluoroethylene) Valve Seat. Selecting the appropriate material according to the application enhances the performance, durability, and compatibility of the Valve Seat. Goa Polymer has the following types of material:
Pure PTFE (Polytetrafluoroethylene): Made of pure PTFE material, it is suitable for a broad range of chemicals, including acids, bases, and solvents. Commonly used in food processing, pharmaceuticals, and chemical industries.
- Excellent chemical resistance
- Low coefficient of friction
- Wide temperature range (-200°C to +250°C)
- Non-reactive and non-stick properties
Glass-Filled PTFE: Made of PTFE with 15-25% filler content, commonly used in chemical processing and mining. It enhances chemical resistance and reduces friction.
- Improved wear resistance compared to pure PTFE
- Maintains chemical resistance and low friction
- Enhanced dimensional stability and rigidity
Carbon-Filled PTFE: Contains 25-35% filler content, ideal for high-friction environments and applications. Commonly used in automotive, electronics, and aerospace industries.
- Increased wear resistance and compressive strength
- Improved thermal conductivity
- Electrical conductivity (static dissipation)
Bronze-Filled PTFE: Contains 40-60% filler content, providing high mechanical strength. Commonly used in hydraulic systems, marine applications, and heavy machinery.
- Excellent wear resistance and high load-bearing capacity
- Enhanced thermal conductivity
- Lower chemical resistance compared to pure PTFE
FAQ’s
1. Why is PTFE the best material for valve seats?
PTFE has excellent chemical resistance, thermal conductivity, and low friction. Using a valve seat made from PTFE is more durable and long-lasting.
2. Can we use PTFE valve seats in high-pressure applications?
Yes, you can use our PTFE valve seats in high-pressure applications. We use high-grade PTFE material to ensure better quality products.
3. Do you have different types of PTFE valve seats?
Yes, we manufacture different types of PTFE seats like glass, carbon, bronze, etc. We also offer customization in the valve seats as per the client’s requirements.
